| Спецификации | Model Name: GT-BE19000
Network Standard: WiFi 6 (802.11ax)
WiFi 7 (802.11be)
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IPv4
IPv6
Product Segment: BE19000 ultimate BE performance: 1376+5764+11529 Mbps
WiFi Data Rate: 2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps
5GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp
6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp
Antenna: External antenna x 8
Transmit / Receive: 2.4GHz 4x4
5GHz 4x4
6GHz 4x4
Processor: 2.6GHz quad-core processor
Memory: 256 MB Flash and 2 GB RAM
Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access)Beamforming: standard-based and universal4096-QAM high data rate20/40/80/160/320 MHz bandwidth
Operating Frequency: 2.4 GHz / 5 GHz / 6 GHz, 2.4 GHz
5 GHz
6 GHz
Operating Mode: Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
I/O Ports: 1 x 10Gbps for WAN/LAN1 x 2.5Gbps for WAN/LAN1 x 10Gbps for LAN3 x 2.5Gbps for LAN1 x RJ45 10/100/1000Mbps for LAN1 x USB 3.2 Gen11 x USB 2.0
Buttons: WPS Button, Reset Button, Power Switch, LED control Button
LED Indicator: WAN(Internet) x110G LAN x11G/2.5G LAN x1WPS x16GHz x15GHz x12.4GHz x1Power x1
Power Supply: AC Input: 110V~240V(50~60Hz)DC Output: 12 V with max. 5 A current
Package Content: GT-BE19000 tri-band gaming routerRJ-45 cablePower adapterQuick Start GuideWarranty card
Product Weight (g): 2000 g
Product Dimensions: 350.41 x 350.41 x 220.6 mm
AiMesh: AiMesh, • Primary AiMesh Router, • AiMesh Node
Game: Game Boost / Acceleration, Game Radar, WTFast, Mobile Game Mode, Gear Accelerator, ROG_First, OpenNAT (Game Profile), Gaming Port, Gaming Network
Parental Control: "Allow you to block access to unwanted websites and apps.", Web & Apps Filters, Time Scheduling, Reward, Parental Control Customized Internet Schedule, • Maximum Parental Control profile : 64, • Maximum Parental Control content filter rule : 64
Guest Network: "The Guest Network provides Internet connection for guests but restricts access to your local network.", "You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings.", Support Guest Network Pro, • Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5, Guest Network Connection time limit, Guest Network Encryption : Open system, WPA/WPA2/WPA3 Personal
Security: AiProtection, VPN, WiFi Encryption : WPA/WPA2/WPA3 PersonalWPA/WPA2/WPA3 EnterpriseOpen System & OWE, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, • Maximum Firewall Keyword Filter : 64, • Maximum Firewall Network Service Filter : 32, • Maximum Firewall URL Filter : 64
AiProtection: AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking
VPN: Instant Guard, VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
Traffic Control: Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, -- Maximum Bandwidth Limiter Rule : 32, Traditional QoS, Traffic Monitor, • Real-time Traffic Monitor, • Wired Traffic Monitor, • Wireless Traffic Monitor, Traffic Analyzer, • Traffic Analysis Period : Daily, Weekly, Monthly, • Website History
WAN: Internet Connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP, Internet Connection Type : Internet Connection Type :
Internet Connection Type : • PPPoE
Internet Connection Type : • PPTP
Internet Connection Type : • L2TP
Internet Connection Type : • Automatic IP
Internet Connection Type : • Static IP
Internet Connection Type : • IPSec, Dual WAN, 3G / 4G LTE Dongle, 4G / 5G Auto Mobile Tethering, Port Forwarding, • Maximum Port Forwarding Rule : 64, Port Triggering, • Maximum Port Triggering Rule : 32, DMZ, DDNS, NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN: DHCP Server, IPTV, LAN Link Aggregation, Manually Assign IP Address, • Maximum Manually Assign IP Address Rule : 128, Wake on LAN (WOL), VLAN
Wireless: MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, • Maximum MAC Filters : 64, Wireless Scheduler, Wi-Fi Radar, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming
USB application: 4G / 5G Auto Mobile Tethering, File System : HFS+, NTFS, vFAT, ext2, ext3, ext4, Safely Remove Disk, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges
User Interface: WEB: ASUSWRT, APP: ASUS Router APP, Operating system : ASUSWRT
Administration: Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update |
