| Спецификации | Model Name: GT-AXE11000
Network Standard: WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
Backwards compatible with 802.11a/b/g/n/ac Wi-Fi
Product Segment: AXE11000 ultimate AX/AXE performance
WiFi Data Rate: 2.4GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps
5GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
6GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
Antenna: External antenna x 8
Transmit / Receive: 2.4GHz 4x4
5GHz 4x4
6GHz 4x4
Processor: 1.8GHz quad-core processor
Memory: 256MB NAND flash and 1GB DDR3 SDRAM
Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access)Beamforming: standard-based and universal1024-QAM high data rate20/40/80/160 MHz bandwidth* The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.
Operating Frequency: Tri-band Wi-Fi: 2.4 GHz / 5 GHz / 6GHz
Operating Mode: Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
I/O Ports: RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4, RJ45 for 2.5G BaseT for WAN/LAN x 1, USB 3.2 Gen 1 x 2
Buttons: WPS Button, Reset Button, Power Switch, WiFi on/off Button, Boost Key Button
LED Indicator: Power x 12.4G x 15G x 16G x 12.5GE Port x 1LAN x 1WAN x 1
Power Supply: AC Input : 110V~240V(50~60Hz)DC Output : 19 V with max. 3.42 A /19.5 V with max. 3.33 A
Package Content: GT-AXE11000 WiFi Gaming RouterRJ-45 CablePower AdapterQuick Start GuideWarranty Card
Product Weight (g): 1782g
Product Dimensions: 328*328*179 mm
AiMesh: AiMesh, • Primary AiMesh Router, • AiMesh Node
Game: Game Boost / Acceleration, Game Radar, WTFast, ROG_First, OpenNAT (Game Profile), Gaming Port
Parental Control: "Allow you to block access to unwanted websites and apps.", Parental Control Customized Internet Schedule, • Maximum Parental Control profile : 16, • Maximum Parental Control content filter rule : 16
Guest Network: "The Guest Network provides Internet connection for guests but restricts access to your local network.", • Maximum Guest Network Rule : 2.4 GHz x 3, 5 GHz x 3, 6 GHz x 3, Guest Network Connection time limit, Guest Network Encryption : Open system, WPA/WPA2-Personal
Security: WiFi Encryption : WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, WPS support, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, • Maximum Firewall Keyword Filter : 32, • Maximum Firewall Network Service Filter : 32, • Maximum Firewall URL Filter : 64
AiProtection: AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking
VPN: VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
Traffic Control: Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, -- Maximum Bandwidth Limiter Rule : 32, Traditional QoS, -- Maximum Traditional QoS Rule : 32, Traffic Monitor, • Real-time Traffic Monitor, • Wired Traffic Monitor, • Wireless Traffic Monitor, Traffic Analyzer, • Traffic Analysis Period : Daily, Weekly, Monthly, • Website History
WAN: Internet Connection Type : Automatic IP, Static IP, PPPoE (MPPE supported), PPTP, L2TP, Dual WAN, WAN Aggregation, 3G / 4G LTE Dongle, 4G / 5G Auto Mobile Tethering, Port Forwarding, • Maximum Port Forwarding Rule : 64, Port Triggering, • Maximum Port Triggering Rule : 32, DMZ, DDNS, NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN: DHCP Server, IGMP Snooping, IPTV, LAN Link Aggregation, Manually Assign IP Address, • Maximum Manually Assign IP Address Rule : 64, Wake on LAN (WOL)
Wireless: MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, • Maximum MAC Filters : 64, Wireless Scheduler, Wi-Fi Radar, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming
USB application: 4G / 5G Auto Mobile Tethering, File System : HFS+, NTFS, vFAT, ext2, ext3, ext4, Safely Remove Disk, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges
User Interface: Operating system : ASUSWRT
Administration: Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
Smart Home: Support IFTTT |
