Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
PTZ control: Yes
PTZ modes: Auto scan, Auto pan
PTZ protocols: DH-SD
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Alarm input/output: Yes
Certification: UL: UL60950-1+CAN/CSA C22.2,No.60950-1
Form factor: Dome
Product colour: White
Housing material: Metal
Protection features: Vandal proof
International Protection (IP) code: IP66
IK code: IK10
Fog proof: Yes
Minimum illumination: 0.05 lx
Tilt angle range: -2 - 90°
Tilt speed: 120 °/sec
Tilt preset speed: 200 °/sec
Pan range: 0 - 360°
Pan speed: 300 °/sec
Pan preset speed: 300 °/sec
Auto flip: Yes
White balance: ATW, Auto, Indoor, Manual, Outdoor
Camera shutter type: Electronic
Preset programs quantity: 300
Camera shutter speed: 1/3 - 1/300000 s
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Progressive scan: Yes
Sensor type: CMOS
Zoom capability: Yes
Optical zoom: 12x
Digital zoom: 16x
Detect distance: 883 m
Observe distance: 353 m
Recognize distance: 177 m
Focal length range: 5.1 - 61.2 mm
Focus: Motorized/Manual
Maximum aperture number: 3
Identify distance: 88 m
Minimum aperture number: 1.6
Closest focusing distance: 1 m
Night vision: Yes
Maximum resolution: 1920 x 1080 pixels
Total megapixels: 2 MP
Video compression formats: H.264, H.264+, M-JPEG
Supported graphics resolutions: 352 x 240, 352 x 288, 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes: 720p, 1080p
Frame rate: 25 fps
Analog signal format system: PAL
Video streaming: Yes
Noise reduction: Yes
Noise reduction technology: Ultra 2D noise reduction, Ultra 3D noise reduction
Gain control type: Auto/Manual
Automatic gain control: Yes
Full HD: Yes
Privacy masking: Yes
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Bit rate: H.264+/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes
Audio formats supported: PCM
Signal-to-Noise Ratio (SNR): 55 dB
Voice codecs: G.711Mu, G.711a
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.3at
Supported network protocols: IPv4/IPv6,HTTP,HTTPS,SSL,TCP/IP, UDP,UPnP,ICMP,IGMP,SNMP,RTSP,RTP, SMTP, NTP,DHCP,DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x
Wi-Fi: No
Cabling technology: 10/100Base-T(X)
Number of users: 20 user(s)
Quality of Service (QoS) support: Yes
Streaming method: Multicast, Unicast
Client interoperability: ONVIF, PSIA, CGI
Built-in HDD: No
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size: 128 GB
Flash memory: 256 MB
Internal memory: 128 MB
Interface: RJ-45
Auto restore after power failure: Yes
IP address filtering: Yes
Intelligent Video Surveillance (IVS) system features: Abandoned object, Face detection, Intrusion, Missing object, Tripwire
Motion sensor: Yes
Web browser: Yes
Management software: Smart PSS, DSS
Power source type: PoE
AC input voltage: 24 V
AC adapter output current: 1.5 A
Power consumption (typical): 12 W
Power over Ethernet (PoE): Yes
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 90%
Mobile operating systems supported: Android, iOS
Height: 155 mm
Diameter: 17 cm
Weight: 1.8 kg
Package weight: 3.3 kg
Number of cameras: 1
Browser supported: IE, Chrome, Firefox, Safari
Number of video streams: 3 |
