Артикул: IR04 1.0
Flash/ROM: 16 MB (128 Mbit) NOR
DDR/RAM: 128 MB (1 Gbit) DDR2
Cellular Standards: 4G Cat. 4
Cellular Antennas: 2× Detachable
Detachable Cellular Antennas Connector: SMA Female
SIM Options: 2× Mini SIM Slots (2FF)
2.4 GHz Wi-Fi Speed: 300 Mbps
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 2× Detachable
Detachable Wi-Fi Antennas Connector: RP-SMA Female
FEM or PA/LNA: 2.4 GHz: 2× Internal
Range Performance: Max: 130 m (427 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall Performance: One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 10 cm (4'')
10/100 Mbps RJ45 Ports: 4
Ethernet Notes: Port 1 is WAN/LAN configurable, and the rest are LAN ports
USB Ports: 1× USB 2.0
Industrial Sockets: 1× DB9 1×|6-PIN 1× | 10-PIN |
