Артикул: WR6500H
CPU Details: 2.0 GHz Quad-core, ARM Cortex-A7
Flash/ROM: 128 MB (1 Gbit) NAND
DDR/RAM: 512 MB (4 Gbit) DDR4
5GHz Wi-Fi Speed: 5765 Mbps
2.4GHz Wi-Fi Speed: 688 Mbps
5GHz Wi-Fi Streams: 4T4R (4×4 MIMO)
2.4GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 6× Fixed
FEM or PA/LNA: 5GHz: 4× External|2.4GHz: 2× Internal
Range Performance: Max: 240 m (787 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall Performance: Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
2.5G RJ45 Ports: 1
Gigabit RJ45 Ports: 4
Ethernet Notes: The 2.5G port is WAN port, the Gigabit ports are LAN ports
LED: System, Internet, Wi-Fi, WPS
DC Input: 12V 1.5A
Power Adapter: Input: 100 ~ 240 V, 50/60 Hz | AC Output: 12V 1.5A DC
Max Power Consumption (W: 17W
