Type: AV transmitter & transceiver
Connectivity technology: Wired
Maximum transfer distance: 100 m
Cable types supported: Cat6, Cat6a
Rack mounting: Yes
Maximum digital resolution: 3840 x 2160 pixels
Maximum refresh rate: 60 Hz
KVM port selection: Push-buttons
Supported resolutions: 640 x 480, 800 x 600, 1024 x 768, 1280 x 800, 1280 x 1024, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 3840 x 2160
Product colour: Black
Material: Metal
LED indicators: Link, Power, Status
Transmitter video port type: HDMI
Transmitter local video port: Yes
Transmitter local video port type: HDMI
Transmitter local keyboard/mouse port type: USB
RJ-45 ports quantity (transmitter): 1
Transmitter USB Type-B ports quantity: 1
Receiver local video port type: HDMI
Receiver local keyboard/mouse port type: USB
RJ-45 ports quantity (receiver): 1
USB port type: USB Type-A
USB 2.0 ports quantity: 4
RS-232 ports: 2
AC adapter output voltage: 5 V
Power consumption (transmitter) (max): 2.59 W
Power consumption (receiver) (max): 1.88 W
DC-in jack: Yes
Transmitter width: 8.21 cm
Transmitter depth: 12.8 cm
Transmitter height: 2.5 cm
Transmitter weight: 320 g
Receiver width: 8.15 cm
Receiver depth: 12.8 cm
Receiver height: 2.5 cm
Receiver weight: 310 g
Package weight: 1.38 kg
AC adapter included: Yes
Cables included: USB Type-A to USB Type-B
Manual: Yes
Mounting bracket(s) included: Yes
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%
HDCP: Yes
HDCP version: 2.3
Extended display identification data (EDID): Yes
Package volume: 3029.9026 cm³
Country of origin: China
Master (outer) case volume: 19566.941 cm³
Master (outer) case net weight: 5.27 kg
Harmonized System (HS) code: 85176200
Master (outer) case width: 300 mm
Master (outer) case length: 336 mm
Master (outer) case height: 194 mm
Master (outer) case gross weight: 6.99 kg |
