Processor: Intel® Core™ Ultra 5 225, 10C (6P + 4E) / 10T, Max Turbo up to 4.9GHz, 20MB Intel Smart Cache
AI PC Category: AI-Ready Workstations
Processor Sockets: 1x FCLGA1851
Integrated Graphics: Integrated Intel® Graphics
Discrete Graphics: None
Chipset: Intel® Q870 Chipset
Memory: 1x 16GB SODIMM DDR5-5600 Non-ECC
Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 128GB (2x 64GB DDR5 CSODIMM)
PCIe NVMe Controller: Integrated NVMe® controller
PCIe NVMe Drive: 1x 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
Audio Chip: High Definition (HD) Audio, Realtek® ALC233VB codec
Power Supply: 170W 89% Adapter
Keyboard: USB, Calliope, Black, Hebrew
Mouse: USB Calliope Mouse, Black
Expansion Slots: PCIe 4.0 x4 and low profile for serial or ethernet adapters
Case Color: Black
Dust Filter: None
Toolless Chassis Screw: Toolless Chassis Screw
Mounting: None
Stand: None
Dimensions (WxDxH): 179 x 182.9 x 37mm with rubber feet (7.0 x 7.2 x 1.5 inches with rubber feet)
Weight: 1.4 kg (3 lbs, maximum configuration)
Onboard Ethernet: Intel® I219-LM, 1x GbE RJ-45
Optional Ethernet: None
WLAN + Bluetooth: Intel® Wi-Fi® 7 BE200, 802.11be 2x2 + BT5.4, vPro®
Front Ports: 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only, 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On, 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), 1x headphone / microphone combo jack (3.5mm)
Rear Ports: 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), 3x USB-A (USB 10Gbps / USB 3.2 Gen 2), one supports Smart Power On, 1x HDMI® 2.1 TMDS, 1x DisplayPort™ 1.4, 1x Ethernet (RJ-45)
Optional Rear Ports (configured): None
Security Chip: Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Physical Locks: Kensington® Security Slot™, 3 x 7 mm
Cable Lock: No Cable
Chassis Intrusion Switch: Chassis Intrusion Switch
System Management: Non-vPro®
Base Warranty: 3-year, Onsite
Included Upgrade: 1Y Premier Support from 3Y Onsite Windchill bundles(CPN)
ISV Certifications: Please visit ISV certifications for Lenovo® Workstations
Mil-Spec Test: MIL-STD-810H military test passed
Operating System: Windows® 11 Pro, Hebrew / English
Bundled Software: None |
